Description
- Stainless steel platform scales with up to four interfaces and intuitive operation, with optional verification
- Industry 4.0: The exchange of data and control commands is optional using up to four interfaces to suit individual requirements: two wired connections (RS-232, Ethernet, USB or analogue module) and two wireless connections (WiFi, Bluetooth)
- Each interface can be set up separately, e.g.:
– Interface 1 (WiFi): Continuous sending to a PC for documentation of a process
– Interface 2 (RS-232): Print stable weight
– Interface 3 (analogue module): Controlling a device when the target weight is reached
– Interface 4 (Bluetooth): Continuous sending to a tablet to monitor a process - Available as an option with alibi memory for paperless archiving of weighing results. This also means the results of weighings with mandatory verification can be electronically evaluated and processed further
- Data query and remote control of the balance using a computer or CRM/ERP systems using the KERN Communication Protocol
- Platform: weighing plate of stainless steel, painted steel base, silicone-coated aluminium load cell with protection against dust and water splashes IP65
- Display device: stainless steel, protection against dust and water splashesIP68. Superior display size: digit height 48 mm, bright backlight for easy reading of weighing results, even in poor lighting conditions, integrated power supply
- Option: Rechargeable battery pack, KERN YKR-01, Option, must be ordered at time of purchase
- For devices that require verification (conformity assessment according to NAWI 2014/31/EU), please include the verification when placing your order, the initial verification is not possible after delivery. Please inform the full address of the location of use for the initial verification
- It is essential that a verified balance which transfers measurements to external devices using an interface, has an alibi memory YMM-06. It is not possible to upgrade later.
| Model | Readability | Weighing capacity | Plate |
| g | kg | mm | |
| IXC 6K-4 | 0.2 | 6 | 300×240 |
| IXC 10K-4 | 0.5 | 15 | 300×240 |
| IXC 10K-4L | 0.5 | 15 | 400×300 |
| IXC 30K-3 | 1 | 30 | 400×300 |
| IXC 30K-3L | 1 | 30 | 500×400 |
| IXC 60K-3 | 2 | 60 | 400×300 |
| IXC 60K-3L | 2 | 60 | 500×400 |
| IIXC 100K-3 | 5 | 150 | 500×400 |
| IXC 100K-3L | 5 | 150 | 650×500 |
| IXC 300K-3 | 10 | 300 | 650×500 |
| IXC 6K-3M | 1/2 | 3/6 | 300×240 |
| IXC 10K-3M | 2/5 | 6/15 | 300×240 |
| IIXC 10K-3LM | 2/5 | 6/15 | 400×300 |
| IXC 30K-3M | 5/10 | 15/30 | 400×300 |
| IXC 30K-3LM | 5/10 | 15/30 | 500×400 |
| IXC 60K-2M | 10/20 | 30/60 | 400×300 |
| IXC 60K-2LM | 10/20 | 30/60 | 500×400 |
| IXC 100K-2M | 20/50 | 60/150 | 500×400 |
| IXC 100K-2LM | 20/50 | 60/150 | 650×500 |
| IXC 300K-2M | 50/100 | 150/300 | 650×500 |
IXC-M: Dual weight range scale with optional verification
