Sysmatec

Heat and cool Block

Block Heater ABH-101A/102A/103A/104A

Block heater is designed for widely use in Chemical, Biochemical, Clinical and other General Labs for heating, digesting, incubating, concentrating and other heating processes.

Temperature Range: Room Temperature+10 °C to 130ºC

Control: PID, no display

Temperature Stability: +/-0.1ºC

Max. Block Number: 1 (101A), 2 (102A), 3 (103A), 4 (104A)

Temperature Maximum difference between 2 identical blocks at 50ºC: +/-0.2ºC

Power Supply 230V, 50Hz or 110V, 60Hz

Dimension (mm) 140x270x110 (101A), 220x270x110 (102A), 275x270x110 (103A), 260X360X105 (104A)

Different blocks availables


Block Heater ABH-101D/102D/103D/104D

Block heater is designed for widely use in Chemical, Biochemical, Clinical and other General Labs for heating, digesting, incubating, concentrating and other heating processes.

Temperature Range: Room Temperature + 10°C to 200ºC

Control: PID, with display

Temperature Stability: +/-0.1ºC

Max. Block Number: 1 (101D), 2 (102D), 3 (103D), 4 (104D)

Temperature Maximum difference between 2 identical blocks at 50ºC: +/-0.2ºC

Power Supply 230V, 50Hz or 110V, 60Hz

Dimension (mm) 140x270x110 (101D), 220x270x110 (102D), 275x270x110 (103D), 260X360X105 (104D)

Different blocks availables


PCR-Cycler type 006

Temperature range 4°C to 99°C

Block uniformity ± 0.5°C

Temperature accuracy ± 0.5°C

End of program cooling below ambient: YES

Maximum heating rate 4.5°C/sec

Maximum cooling rate 3°C/sec

Heated lid temperature 100°C to 115°C

Heated lid enable/disable YES

Program naming using alpha keys YES

Program password protection YES

Number of programs (3 step) 37

Height 185 mm

Width 185 mm

Length 330 mm

Weight 6.8 Kg

AC INPUT 120V or 230V with Switch


Cold Keeper

Most Economic Device To Replace The Ice Bucket. Simply plug it in, turn it on, and put the sample in, the Cold Keeper can keep your sample at low temperatures for long periods.

20 sample compartments in each block, sizes from 0.2ml to 2ml, simply change format of the compartments when you need different sizes. The unit can also use the ceramic-coated aluminum beads to accommodate various sample vials at the same time.

There are two different models: ACK-301, the analog device, keeps your sample at 0°C, and ACK-302, with display and setting, You can adjust temperature from 0°C to any set point lower than room temperature.

ACK-301 ACK-302
Temperature Range (°C) 0°C - 4°C with no adjustment 0°C to room temp -5°C
Temperature Accuracy - - - ±1°C

Cooling Technology

Peltier
Power Supply Input 90-230V, output 12V, 5A, 60 W Input 90-230V, output 12V, 5A, 60 W
Dimension 88WX188LX158H 88WX188LX158H
Weight 2 KG 2 KG


Dry bath H2O3

modular

0-100 °C depending on the model

compact

Model H2O3-H: ambiant- 100 °C

Model H2O3-PRO: 0-100 °C, cooling/heating, time and temperature control, automatically cooled down to 4 °C after program completes

available blocks:


Melting Point Device DMP-100

It is a economic and easy-use melting point device. With a precise thermistor control system, the measurement range of the device is excellent, giving 0.1ºC resolutions on display.

The device is designed to simultaneously measure two samples. The internal LED light source, together with clear magnified lens and tilt rear feet aids users to have a broader and clearer view.

The measurement ranges from room temperature to 300ºC. The two different ramping speed modes make measurement much quicker and convenient.

  • Temperature accuracy (ºC ) ± 1.0 at 20ºC, ± 2.5 at 300ºC
  • Display resolution (ºC ) 0.1
  • Fast Stage Ramp rate (ºC/min ) 20 fixed
  • Slow Ramp rates adjustable between 1 to 10
  • Dimensions (w x d x h) 160 x 220 x 170mm
  • Net weight 1.8 Kg
  • Electrical supply 230V, 50Hz, 75W


Multi unit Kjeldahl apparatus

For flasks from 250 up to 1000 ml.

Spillproof– Stainless Steel Heater.

Stepless– heat control.

Includes 4 support rods and 4 clamps.

Durable housing is chemically resistant.

Built-in electronic controller regulates element temp. to 750°C, 2 ranges: low & high.

Robust aluminium construction permits operation of the units as required by extraction and distillation processes.

'Heat on' light for each recess indicates when power is being supplied to the heater.

For maximum operator protection, models are grounded should spillage or flask breakage occur.

Units are designed with a built-in stainless steel liner that gives electrical and mechanical protection against spillage & enables easy cleaning.

Lower profile for space-saving convenience.

Ideal for repetitive extracting (kjeldahl, soxhlet, and other extraction procedure), refluxing & distilling laboratory applications.

Analog controller built-in system.

Ideal for all brands round flasks

Model K-6, 6 Positions

  • Up to 6 flasks, 220 Volt (or 110V), 6x550 Watt
  • Dimensions: (WxHxD) 80x19x20 cm (D includes rear bracket for support rod)
  • Nett weight: 6.8 Kgs

Model: K-4, 4 Positions

  • Up to 4 flasks, 220 Volt (or 110 V), 4 x 550 Watt
  • Dimensions: (WxHxD) 60x19x20cm (D includes rear bracket for support rod)
  • Net weight: 4.8 Kgs


Soxhlet Extractors

For the extraction from solids with solvents.

The solvent is recirculated continuously and distilled from the extracted sample before contacting the solid again. The extract is concentrated in the distillation flask.

The method allows an effective separation with relatively small amounts of extracting solvents.

The complete apparatus consists of a round bottom flask and a compact and robust designed extractor with NS flask connection.

Ref. nr. Extractor Vol (mL) Condenser NS Flask Volum (mL)
5.3600.25 30 29/32 100
5.3600.31 70 34/35 100

5.3600.37

100 45/40 250
5.3600.43 150 45/40 250
5.3600.46 200 45/40 250
5.3600.49 250 45/40 500
5.3600.52 300 60/46 500
5.3600.58 500 60/46 1000
5.3600.70 1000 71/51 2000


Multi Einheit Kjeldahl Gerät

Heating hood with housing Series GH

They have a crocheted inner jacket of glass fiber and are used for heating liquids in round glasses.

The heater is made of a NiCr alloy 8020. It is wrapped by a glass tube and is crocheted with a yarn of glass fibers in the inner jacket of the heating hood. Thus, the heat is uniformly transmitted to the glass flask. The glass tube and the glass yarn also serve as insulation. To ensure that no heat can get into the outer jacket, the inner heating jacket is insulated with a glass wool.

The outer jacket is made of aluminum and consists of three parts: floor, housing and cover.

These parts are electrostatically stained. The housing heating hoods are built in sizes from 25 ML to 6000 ML.

Both models, -GHST and GHAP- can also be fixed. they have a specially designed fitting for this.

Series GHST-without electronic temperature control:

The sizes 25 ML and 50 ML are produced with a heating conductor and have one heating zone. The size 100 ML is produced with a heating conductor, but can work with ½ power or with full power through the built-in minmax switch. The sizes 250 mL-6000 mL have all two heating zones and a min-max switch which allows to operate with only one heating zone or to connect the second heating zone as required.

Series GHAP-with electronic temperature control:

These heating hoods all have a power control, which allows the temperature to be set continuously. The sizes 25 mL to 100 mL have a heating conductor and one heating zone. The sizes 250 mL to 6000 mL have two heating zones and a min-max switch which allows to operate with only one heating zone or to connect the second heating zone.

The nominal voltage is 230 V.

The heating conductor temperature can reach a maximum of 450 ° C.

The heating hoods have protection class I, degree of protection IP00.

All models come as standard with a personal protection adapter.

Model Volume (mL) Flask diameter (rund, mm) Power (W)
GHAP25ML1 25 41 50
GHSP25ML1 25 41 50

GHAP50ML1

50 51 70
GHSP50ML1 50 51 70
GHAP100ML1 100 64 110
GHSP100ML1 100 64 110
GHAP250ML2 250 85 200
GHSP250ML2 250 85 200
GHAP500ML2 500 105 280
GHSP500ML2 500 105 280
GHAP1000ML2 1000 131 450
GHSP1000ML2 1000 131 450
GHAP2000ML2 2000 165 700
GHSP2000ML2 2000 165 700
GHAP3000ML2 3000 185 760
GHSP3000ML2 3000 185 760
GHAP4000ML2 4000 207 860
GHSP4000ML2 4000 207 860
GHAP5000ML2 5000 223 1100
GHSP6000ML2 5000 223 1100
GHAP6000ML2 6000 236 1300
GHSP6000ML2 6000 236 1300


Multi Einheit Kjeldahl Gerät

Standard heating hood series SH

They have a crocheted inner and outer mantle made of glass fibers and are used to heat liquids in round glass. flask. The heat conductor is made of a NiCr alloy 8020. It is wrapped by a glass tube and is crocheted with a yarn of glass fibers in the inner jacket of the heating hood. Thus, the heat is uniformly transmitted to the glass flask. The glass tube and the glass yarn also serve as insulation. To ensure that no or only a little heat can reach the outer jacket, the heating hood is insulated inside with a glass wool.

The heating hoods are built in sizes from 25 ML to 20 L.

The sizes from 25 mL to 250 mL have a closed outer mantle. The sizes from 500 mL have a bottom hole with a diameter of 60 mm.

The sizes from 25 mL to 100 mL are provided with one heating zone and an on /off switch. The sizes from 250 mL have 2 heating zones and a heating zone switch.

The sizes 25 ML to 100 ML are delivered as standard with 4 splints and the sizes from 250 mL with 4 fastening hooks, so that the heating hoods can be fixed easyly.

The nominal voltage is 230 V.

Bottom hole: 60 mm (from 500 mL volume)

The heating conductor temperature can reach a maximum of 450 ° C.

The heating hoods have protection class I, degree of protection IP00.

All models come as standard with a personal protection adapter.

Model Volume (mL) Flask diameter (rund, mm) Power (W)
SH25ML1 25 41 50
SH50ML1 50 51 70

SH100ML1

100 64 110

SH250ML1

250 85 200

SH500ML2

500 105 280

SH1000ML2

1000 131 450

SH2000ML2

2000 165 700

SH3000ML2

3000 185 760

SH4000ML2

4000 207 860

SH5000ML2

5000 223 1100

SH6000ML2

6000 236 1300

SH10ML2

10000 279 2000

SH120ML2

20000 345 2800


Multi Einheit Kjeldahl Gerät

Slim PCR Cycler Theater4X4

It is a new generation of PCR mini cycler, substantially small and thin. The thickness is merely 4 cm. It has a user friendly interface employing the leading technology touch screen. Without training, any person can play with the slim cycler and finish setting in seconds. It is the only energy efficient PCR cycler with 12V DC power and portable in mobile application.

Features

  • Compact, can be used in clean bench
  • Save Time, no waiting time, finish setting in 30 s
  • Save Energy, Portable & Energy Efficient
  • Capacity: 16 x 0.2 ml
  • Temperature range: 8-99 °C
  • Temperature resolution: 0.1 °C
  • Temperature precision: +/- 0.2 °C
  • Temperature Evenness(Minimize edge effect): +/- 0.2 °C
  • Time range: 1 s to 60min
  • Programs: Long-PCR, RT-PCR incubation programs
  • Number of Stored Programs: 15
  • Number of cyclers: 1-99
  • Control Interface: touch screen, turning knob
  • Dimensions: 200x200x40 mm
  • Net weight: 2.1 kg
  • Max.Ramping Rate: 3 °C/s
  • Heated Lid Temperature: 105 °C
  • Operation ambiant temperature: 8-30 °C
  • Power supply: 12 VDC
